Thin Rectangular Warner-Bratzler Blade

The basic concept and design of the Warner Bratzler shear device have been subject to modification and improvement over the years. Yet, the familiar blade, with its triangular notch in the middle, remains one of the most widely used devices to provide measurements of meat texture quality.

The width of the blades and the position of the triangle; the speed of the test; the shape, mass, and orientation of the test sample are of course important to interpretation of the results of shear tests but as is always found with “standard” methods and attachments there will always be reasons for modification of the specification of a test attachment and groups of researchers who prefer to move away from a standard to a method that suits their particular research purpose.

One such group is responsible for the development of a variant of the original Warner-Bratzler Blade. This blade set is as used in the European Honikel method for meat testing and has a thin rectangular slot blade. As a spin-off of a workshop on pork quality, held in Helsinki in 1992, a group of scientists with many years of experience in the field of meat quality assessment convened in 1993 for the first time, and subsequently in 1994 and 1995 in Kulmbach at the German Federal Centre for Meat Research to develop internationally accepted reference methods. In the Autumn of 1997 these methods (which include this method for tenderness) were brought into their final form at the Meat Industry Research Institute of New Zealand.

Although Warner Bratzler devices and sample configuration are extremely variable, the recommended equipment according to this “European” network is as follows. The blade should be 1.2mm thick with a rectangular hole 11mm wide and at least 15mm high. The hole should have square smooth edges and the blade should be drawn or be pushed at 50-100mm/min between side plates positioned to provide a minimum gap between blade and plates. The sample should be cut from a block of cooked meat and taken to avoid damage.

Sample strips should be cut with a 100mm² (10mm x 10mm) cross-section with the fibre direction parallel to a long dimension of at least 30mm. The sample should be sheared at right angles to the fibre axis. The parameters to be measured from the force deformation curve are the peak force (the maximum recorded) and the total energy. Initial yield may be useful in some instances but will not always be apparent.

Samples with small rectangular profile.

• Preparation of small samples
