Cooked Pasta Quality Firmness Rig

An AACC Standard method 66-50.01 for the measurement of pasta cooking quality, with respect to Firmness, was first approved in 1989 and is now widely used. Like most instrumental tests used to evaluate pasta quality, this method involves large deformation measurements on the samples tested. It specifies the use of a knife blade, machined to a 1mm flat across the cutting edge, which measures the force required to cut five strands of spaghetti (or approximately equivalent width of other pasta forms) positioned adjacent to one another.

Firmness is defined in this method as the work in grams-centimetre required to shear one piece of pasta (e.g. one strand of spaghetti). The maximum cutting force per unit area is also used as a measure of spaghetti firmness and the results of both of these tests have been found to correlate well with data obtained by subjective cooking tests.

An example of the use of this type of test is in the determination of cooking tolerances of pasta samples according to the raw materials and processing methods utilised. The mean values are obtained from triplicate measurements of each sample and are the results for single strands of spaghetti.

This method has since been revised (66-52.01) and uses a slightly different blade – A/LKB-F2. The new method (66-52.01) contains more specific detail on sample preparation (66-51.01) and improved explanation of test settings and analysis and was approved in March 2019 by the AACCI from the study of methods for measuring spaghetti fully cooked time (FCT) and cooked spaghetti firmness (absolute peak force, area to absolute peak force, total downstroke area, and total positive area).

This blade does not tend to be used for any other method or sample type.

Uniform pasta strands.

• Knife is made from perspex which is a soft material – this probe is therefore easily damaged

Full installation instructions are provided within the Education Zone of the latest Exponent/Connect software version and on the technical information sheet accompanying this product.

Stable Micro Systems probes and attachments are commonly made from four materials: anodised aluminium (AA6082 T6), stainless steel (316 T), Delrin (acetyl copolymer) and Perspex (polycarbonate).

In general use, probes and attachments made from these materials will be suitable for testing food products and inert non-food materials.

The four materials listed above are not universally resistant to all types of chemicals and as such the compatibility of the probe/attachment material with the product (to be tested) must be established to prevent damage to the probes and attachments. If the compatibility of the product with the probe is unknown to the customer then the chemical information about the product (Material Safety Data Sheet or Product Data Sheet) should be submitted to Stable Micro Systems. Stable Micro Systems will then assess the suitability of the probe/attachment material for use with the product and advise accordingly. If this advice is not sought then Stable Micro Systems will not accept liability for probes/attachments damaged by chemical attack from the product being tested.

All probes and attachments may be cleaned in warm (or hand hot) water using a mild detergent. A soft brush may be used but abrasive cleaning aids should be avoided. Stable Micro Systems products should not be microwaved or cleaned in a dishwasher.

Screw threads should be lightly lubricated after drying using a light lubricant, e.g. petroleum jelly, mineral oil. This will aid the fitting and unscrewing of the item. Each component of a probe or attachment should be wrapped separately when stored, to avoid scratching or chipping. This will safeguard against any unnecessary damage to the accessory.
